| TYPE | VOLTAGE (V) | POWER (W) | WATER OUTPUT DAILY (Liters/day) | LIFT HEAD (M) | OUTLET SIZE (Inch) | DIAMETER (mm) |
|---|---|---|---|---|---|---|
| Series 1 | ||||||
| JCS4-4.0-34 | 36 | 370 | 12,000 to 20,000 | 5 to 30m | 1.25 | 92 |
| JCS4-4.0-75 | 48 | 550 | 12,000 to 20,000 | 5 to 60m | 1.25 | 92 |
| JCS4-4.0-103 | 48 | 750 | 12,000 to 20,000 | 5 to 85m | 1.25 | 92 |
| JCS4-4.0-134 | 72 | 1100 | 12,000 to 20,000 | 5 to 110m | 1.25 | 92 |
| JCS4-4.0-166 | 252 | 1500 | 12,000 to 20,000 | 5 to 145m | 1.25 | 92 |
| JCS4-4.0-243 | 288 | 2200 | 12,000 to 20,000 | 5 to 210m | 1.25 | 92 |
| JCS4-4.0-333 | 288 | 3000 | 12,000 to 20,000 | 5 to 300m | 1.25 | 92 |
| JCS4-4.0-458 | 288 | 4000 | 12,000 to 20,000 | 5 to 420m | 1.25 | 92 |
| Series 2 | ||||||
| JCS4-5.0-36 | 36 | 370 | 20,000 to 28,000 | 5 to 25m | 1.5 | 92 |
| JCS4-5.0-55 | 48 | 550 | 20,000 to 28,000 | 5 to 40m | 1.5 | 92 |
| JCS4-5.0-71 | 48 | 750 | 20,000 to 28,000 | 5 to 60m | 1.5 | 92 |
| JCS4-5.0-93 | 72 | 1100 | 20,000 to 28,000 | 5 to 80m | 1.5 | 92 |
| JCS4-5.0-137 | 252 | 1500 | 20,000 to 28,000 | 5 to 120m | 1.5 | 92 |
| JCS4-5.0-181 | 288 | 2200 | 20,000 to 28,000 | 5 to 160m | 1.5 | 92 |
| JCS4-5.0-244 | 288 | 3000 | 20,000 to 28,000 | 5 to 210m | 1.5 | 92 |
| JCS4-5.0-326 | 288 | 4000 | 20,000 to 28,000 | 5 to 300m | 1.5 | 92 |
